Double color melamine ware making machine with double proportional valve system
Brand:
ShunhaoPayment:
LC, TTProduct Origin:
ChinaShipping Port:
XiamenSupport Service:
Life-time ServiceHow to Make Two-color Patterned Melamine Dinnerware?
1. To make two-color melamine dinner plates, two carefully combined colors of melamine molding powder are pressed separately, the colors are very vibrant and enhance the overall appearance of the dinner plate.
2. In addition to the combination of two colors, decals are also applied to the plates to increase visual appeal, forming a harmonious and unique melamine product.
Technical Parameters of Shunhao 300 Ton Hydraulic Compress Machine
No. |
Content |
DTM 300 |
1 |
Main Cylinder Nominal Pressure |
300Tons |
3 |
Maximum Working Pressure |
210kg/cm2 |
4 |
Main Cylinder Piston Diameter |
Ø450mm |
5 |
Main Cylinder Working Stroke |
550mm |
6 |
Adjustable Table Distance |
500~850mm |
7 |
Heating Plate Size |
720*720/780*720mm |
8 |
Working Layers |
1 layer |
9 |
Heating Plate Material |
45# |
10 |
Tension Column (Heat Treatment Grinding) |
Ø120*2400mm |
11 |
Oil Hydraulic Pump |
21Mpa |
12 |
Motor Specifications |
15HP |
13 |
Heating Sheet Total Power |
27.45KW |
14 |
Machine Total Power |
38.45KW |
15 |
Machine Size(length * width * height) |
2.3*1.78*2.9 M |
16 |
Machine Weight |
8600KGS |
PS: Specifications subject to change without notice
How to Choose the Right Melamine Dinnerware Machine?
1. One crucial factor to consider when choosing a melamine dinnerware machine is the design concept. Shunhao machines boast 100% Taiwanese technological expertise, inheriting the earliest design concepts from Japan. Notably, the Shunhao double-color molding machine is the only one in the industry to feature a genuine dual-proportion valve system.
2. Another important consideration is the sturdiness of the casting. Shunhao machines ensure robust casting, providing the necessary stability and durability required for the manufacturing process.
3. Shunhao melamine dinnerware machines are equipped with industry-standard electrical accessories which not only ensure compatibility but also facilitate easy maintenance and repair, minimizing downtime and enhancing overall productivity.
